Description
The BL LG 17 serves as a basic unit for all GANN air velocity probes. It is the first meter that uses an OLED display. This enables a new, intuitive way of menu navigation, which makes operation easier. Current readings can, for example, be displayed as a numeric value, in a line diagram or as a bar graph.
The device features a continuous measurement mode, to monitor an air flow over a longer period of time (up to 30 minutes).
Another function is used to define an area or a circle in order to be able to calculate a volumetric flow from the air velocity.
The measuring meter can be used in a variety of applications such as monitoring rooms, HVAC, blower door tests, laminar air flow control (clean-room technology), etc.
Specifications
- Ambient pressure and air temperature can be used to adjust the air velocity reading. The ambient pressure is determined automatically, but can also be set manually; the air temperature can be set manually on the device
- Adjustable limits with acoustic alarm signal
- Operating languages: German and English
- Unit system: metric and imperial
- Min, Max and Hold functions for measured values
- Storage of the 5 most recent measured values
- Power supply: a 9-volt battery is included
| Length | 0.175 m0.574 ft (0.175 m) |
| Width | 0.05 m0.164 ft (0.05 m) |
| Height | 0.03 m0.098 ft (0.03 m) |
| Weight | 180 kg396.828 lb (180 kg) |
Packages
The meaning of the icons
A filled icon = Measuring task is supported by the instrument unit - the respective accessories are included in the package.
A half filled icon = Measuring task is supported by the instrument unit - but this package does not include the respective accessories. This means you can expand the scope of use cases at any time by purchasing additional electrodes & probes.
A transparent icon = Measuring task is not supported by the instrument unit.
