BL Compact S
Have questions?Description
The BL Compact S unit is an electronic moisture meter for various wood fuels, suited for measuring various types of hardwood or softwood.
The sensor pins at the top of the meter allow for moisture measurements to be carried out in wood of up to 30 mm in thickness. The measuring depth is approx. 15 mm.
Benefits:
- Environmental protection (lower emission)
- Oven and chimney protection (better combustion)
- High energy yield, since the wood is burned in its optimum moisture state
Measuring ranges
Resistance-based measuring
Measuring ranges
10 to 50 % (dry mass)
10 to 34 % water content
Suitable electrodes & probes
2 Measuring instruments compatible
2 Measuring instruments compatible
Specifications
- Handy pocket-sized moisture measuring meter for fast single and series measurements
- Direct readout of wood moisture in weight-% or water content in % on the LCD, resolution: 0.1 %
- 2-level wood species correction for more than 300 types of wood
- Min, Max and Hold functions for measured values
- Power supply: a 9-volt battery is included
| Length | 0.175 m0.574 ft (0.175 m) |
| Width | 0.05 m0.164 ft (0.05 m) |
| Height | 0.03 m0.098 ft (0.03 m) |
| Weight | 0.16 kg0.353 lb (0.16 kg) |
Downloads
Manuals
- BL_Compact_S_BA_V3.0_DE1 MB
- BL_Compact_S_V2.1_EN679 KB
- BL_Compact_S_V2.1_FR730 KB
- BL_Compact_S_V2.1_IT975 KB
- BL_Compact_S_V2.1_FI750 KB
Quick Instructions
- BL_Compact_S_QSG_V1.0_DE969 KB
